Product Specifications
 |
EXTERNAL CONNECTIONS
- Dual 4-prong MOLEX-style plugs (single plug on models less
than 20" width), contain both power and serial communications
- 15V DC supplied by external 120/240V power supply, UL
approved
- Signs may be connected from either plug
- Multiple signs may be daisy-chained from one external
power/communications connection
|
MESSAGE DISPLAY AREA
- 7 rows x 48 columns
- .25" nominal pixel spacing, horizontal & vertical
- Minimum of eight (8) 5x7 characters, full upper and lower
case
- Automatic proportional spacing typically yields additional
characters
|
 |
ANMATION & GRAPHICS
- Scroll left, right, up & down
- Marquee
- Instant appear & disappear
- Fade-in & fade-out
- Spin
- Come & Go
- Full individual pixel control for custom graphics
|
 |
 |
COMMUNICATIONS & PROGRAMMING
- 19200 baud serial with integral IRDA link
- Each sign is independently addressable (for networking via
remote link)
- Custom embedded controller with 64K EEPROM
- Internal clock/calendar with 2-week power-loss backup
- Windows-based PC programming utility with on-screen
emulation
- Optional Palm™-type handheld interface for message downloading
(limited editing capability)
|
All specifications are subject to change without notice.
For more information, send email to
or contact Neu-Solutions, Inc. at 1-800-493-0080
|
™
